Fuelflex

Product description and applications

Fuelflex is a tough abrasion resistant layflat fuel transportation hose with integrated anti-static capabilities. It is suitable for:

  • Fuel transportation
  • Re-fuelling
  • De-bunkering
  • Salvage

Benefits and cost saving features

  • Woven jacket of high tenacity Polyester filament yarns
  • Polyurethane coating applied with through extrusion
  • High abrasion resistance
  • Excellent UV resistance
  • Excellent fuel resistance
  • Low coil volume for easy handling
  • Continuous lengths up to 200m
  • Certified to MIL PRF 370J Type C

Specifications

Inside Diameter Weight (g/m) Short Length Bursting Pressure (Bar)
50mm (2″) 560 60
64mm (2½”) 650 50
76mm (3″) 960 50
102mm (4″) 1400 50
127mm (5″) 0850 40
152mm (6″) 2400 40
202mm (8″) 3380 35

The manufacturer reserves the right to modify specifications without prior notice.
