DeepLine

DeepLine Product Description and Applications

DeepLine is a tough abrasion resistant hose specifically
designed for extremely deep pump settings where Boreline has
it’s limitations.

DeepLine is suited for:

• Deep Submersible Pump installations
• Mine Dewatering
• Deep well applications

Benefits and Cost Saving Features considering DeepLine application:

• Quick, easy, inexpensive installation and retrieval
• Fully resistant to corrosion, scaling & biological growth
• Light weight
• Less manpower required
• Excellent hydraulic performance
• Advantageous in restricted working area
• Flexible from -40°C to +70°C
• Superb hydraulic performance
• Available in up to 400 m length

Specifications

Diameter	3″ 76 mm	4″ 102 mm
Burst Pressure	100 bar	100 bar
Recommended Max Operating Pressure	42 bar	42 bar
Approx Tensile Strength	12 000 kg	16 000 kg
Recommended Max Working Load	4 000 kg	5 200 kg
Weight of DeepSet	1.3 kg/m	2 kg/m
Minimum Well Diameter	202 mm	250 mm
Coupling Diameter	125 mm	145 mm
Coupling Ring Torque setting	45 Nm	80 Nm
SS Coupling weight	9 kg	11.7 kg
Approx Weight of Water	5.1 kg/m	10.2kg/m

The manufacturer reserves the right to modify specifications without prior notice.
Please contact us on any technical queries
sales@hosessa.com or +27 21 948 3971
